Specifications*:

Engine size:

600

Cylinders:

1

hp/kW:

57/42

Vehicle weight (kg):

163

Seat height (mm):

910

Valve clearance (intake):

0,10-0,15 MM KALT

Valve clearance (exhaust):

0,15-0,20 MM KALT

Carburettor air screw:

EINSPRITZUNG 45MM

Tyre pressure (front):

1,8 (2,0) BAR

Tyre pressure (rear):

2,0 (2,2) BAR

Spark plug 1:

NGK CR8EB

Spark plug 2:

NGK CR8EIX

Electrode gap:

0,7-0,8 MM

Fork tube diam.:

45 MM USD-GABEL

Front/rear sprockets:

15/38 ZÄHNE

Chain/Final drive:

DID 520 V6 KETTE

Capacities*:

Fork oil per rod:

600 ML SAE 5W

Engine oil w/o filter:

1,6 L SAE 10W-50

Engine oil with filter:

1,8 L VOLLSYNTHESE

Brake fluid:

DOT 4

Fuel:

12,0 LITER

Coolant:

1,2 LITER
